Features:
1. 7-inch color touch screen, navigation-style operation
2 supports the measurement of dissolved oxygen concentration, dissolved oxygen saturation, dissolved oxygen current and temperature values;
3 intelligent operating system, with method management, electrode management, calibration management, data management and user management functions;
4 supports electrode management, can manage up to 5 DO electrodes, each electrode can save 20 sets of calibration records; support for calibration and editing functions to facilitate calibration;
5 to support zero-oxygen and full-scale calibration, support for atmospheric pressure and temperature automatic compensation, support self-stirring dissolved oxygen electrode;
6 kinds of reading mode: Smart-Read: "fast, medium, strict, custom" a variety of balance conditions optional; Timed-Read: timed measurement and timing automatic interval measurement 2 kinds of timing reading mode optional; Cont- Read: Clearly grasp the continuous process of sample changes;
7 to support the storage of up to 100 sets of measurement methods; support for storage of dissolved oxygen concentration and dissolved oxygen saturation of 1000 sets of measurements, in line with the GLP standard; with statistical data, allowing users to measure the results of statistics, access, analysis, comparison, save;
8 support USB, RS232 connection PC, serial printer; allow print output measurement results;
9 supports Chinese and English languages; support for firmware upgrades, support U disk hot swappable; support for direct connection to the autosampler. Technical Parameters:
Dissolved oxygen saturation of 0.1%
Temperature 0.1 ℃
The basic error of dissolved oxygen ± 0.10mg / L
Dissolved oxygen saturation ± 2.0%
Temperature ± 0.1 ℃
Atmospheric pressure compensation (60.0 ~ 110.0) kPa
Salinity compensation (0.0 ~ 50.0) g / L
Power Power Adapter (Input: 100-240VAC, 1.35A; Output: 24VDC, 3A)
Dimensions (mm); Weight (kg) 280 × 280 × 130; 2.5
Features:
1. 7-inch color touch screen, navigation-style operation
2 supports the measurement of dissolved oxygen concentration, dissolved oxygen saturation, dissolved oxygen current and temperature values;
3 intelligent operating system, with method management, electrode management, calibration management, data management and user management functions;
4 supports electrode management, can manage up to 5 DO electrodes, each electrode can save 20 sets of calibration records; support for calibration and editing functions to facilitate calibration;
5 to support zero-oxygen and full-scale calibration, support for atmospheric pressure and temperature automatic compensation, support self-stirring dissolved oxygen electrode;
6 kinds of reading mode: Smart-Read: "fast, medium, strict, custom" a variety of balance conditions optional; Timed-Read: timed measurement and timing automatic interval measurement 2 kinds of timing reading mode optional; Cont- Read: Clearly grasp the continuous process of sample changes;
7 to support the storage of up to 100 sets of measurement methods; support for storage of dissolved oxygen concentration and dissolved oxygen saturation of 1000 sets of measurements, in line with the GLP standard; with statistical data, allowing users to measure the results of statistics, access, analysis, comparison, save;
8 support USB, RS232 connection PC, serial printer; allow print output measurement results;
9 supports Chinese and English languages; support for firmware upgrades, support U disk hot swappable; support for direct connection to the autosampler.
