JY-9000 Oil rapid multi-parameter tester Introduction
It can be used in the field of oil products, rapid determination of kinematic viscosity of the oil again, moisture content, TBN, total acid, insoluble. Feature
The instrument uses a microcomputer control technology, interface prompts the interactive mode, temperature, pressure, optical, flow, and so the potential for control and signal processing, to complete the process of the testing process, correct and reliable viscosity, moisture, TBN, total acid, and insolubles result data. And can store more than 100 groups of test results or through an external mini-printer to print the data labels. Technical Parameter
1, the kinematic viscosity
Test range: 6 ~ 300mm2 / s
Test temperature: 20 ℃ ~ 100 ℃
test accuracy: ± 4%
Test time: ≤15min
Amount of sample: 2mL
2, water
Test range: 0 to 5%
test accuracy: 0 ~ 2%: ± 0.1% (absolute error)
2 - 5%: ± 0.2% (absolute error)
Test time: ≤6min
Amount of sample: 2mL
3, TBN, total acid number
Test range: total acid number: 0 ~ 2.5mgKOH / g
TBN: 0 ~ 20mgKOH / g
4, insolubles
Test range: 0 to 3%
Amount of sample: 1ml
Test time: ≤3min
test accuracy: comply with GB / T8926 requirements in 9.2.1
5, the working voltage: AC220V or DC12V
6, Dimensions: 400 × 165 × 280mm (L × W × H)
7, Weight: 25Kg
8, can store data: 200 groups
9, with external computer printer
10, power 100w
JY-9000 (portable) oil and oil multi-parameter rapid tester can be used for on-site determination of the kinematic viscosity, moisture content, total alkalinity, total acid value and insoluble matter of oil.
