Brief introduction: Nano group: nano-coating , ink, nano-electronics , nano metal powder , nano-ceramic , nano oxides , protein, polymer latex , paints, pigments and all other nanomaterials research, production and use of powder , etc. , the particle size distribution of the emulsion testing. Micron: particle size distribution of chemical materials, electronic materials, battery materials, paper making, metallurgy, ceramics, building materials, abrasive, medicine, paint, cement, food, pesticides, calcium carbonate, talc, kaolin, alumina, diamond, rare earth, catalyst, wollastonite, tourmaline, mica, barite, aluminum powder, iron powder, magnesium powder, molybdenum powder, copper powder, zinc powder, foaming agent, graphite, paint and other industries, such as dry powder emulsion. Features 1, the mechanical analysis of the equipment is wide dynamic range and good repeatability, the operation is simple and convenient. 2, is a powerful instrument that can test micron grade of nanoscale powder and powder, two kinds of test functions only need to click the mouse, for a few seconds to realize the fast transformation. 3, instrument, sample pool, integrating optics, circuit integration of ultrasonic dispersion, mixing cycle, automatic cleaning, automatic commander to zero under computer control. 4, have two kinds of optional sample system, meet the demand of various tests. 5, user can choose according to the actual needs of different data processing method and the distribution model. 6, instrument contains many kinds of distribution patterns, have free distribution, logarithmic normal distribution, R - R distribution, etc, can satisfy the needs of different sample testing and comparison. Technical indicators Test range : 1nm ~ 2000μm
Nano segment : Test 1nm ~ 10000nm, using photon correlation spectroscopy ;
Micron sections : Test 0.02μm ~ 2000μm, with full -scale Mie scattering ;
Break Range : Pursuant to the actual size of the sample status , menu choices nano segment micron sections or full-scale test section . Different range of test , click on the control keys automatically after the conversion is completed , no need to replace parts.
Signal source: semiconductor laser light source wavelength 0.6328 μm pair , good stability and long service life. Detector: more than 80 yuan detector , high gain and low noise photomultiplier tube , double pipe testing.
Test accuracy : micronized D50 test repeatability error ≤ ± 1% ( national standard ) .
Injection system : with a micro static sample cell cycle injector pool two kinds , you can choose to use.
Test software : in Windows XP / Windows 7 (32 -bit) systems running the software in Chinese and English versions , testing user-friendly, menu prompts complete , easy to operate .
Resulting output: table shows the particle size distribution and graphs , and D10, D50, D90, D97, the average particle size and specific surface area and particle size distribution curve data . Test results can be displayed directly , save and print can also be converted to image files and text files and other format Power supply : AC220V ± 10% 50Hz Power: 300W
Environmental requirements: use of the environment should be clean , temperature :0-40 °C
Instrument Dimensions: Length 880mm Width 410mm height 500mm Instrument Weight : 90kg
