CHY-G Electronic Wall Thickness Bottom Thickness Tester Introduction: The CHY-G electronic wall thickness gauge is suitable for measuring the thickness of the bottom and wall of glass and plastic bottles in industries such as food, medicine, and cosmetics. It can meet the measurement of wall thickness and bottom thickness of products such as infusion bottles, beer bottles, oral liquid bottles, ampoules, penicillin bottles, PET plastic bottles, etc. characteristic: 1. 7-inch color touch screen, electronic intelligent control, automatic grouping and statistics of maximum, minimum, and average values 2. Real time display of rotation angle displacement to ensure accurate measurement and return to its original position 3. Meet two testing methods for glass bottle bottom thickness and wall thickness 4. The system comes with a micro printer, allowing unlimited data storage on the upper computer 5. Professional computer testing software, curve chart display, data saving, EXCEL statistics 6. Software user hierarchical permission management, data statistics, and audit functions meet industry requirements Technical parameters: Instrument range: 0 ~ 12.7 mm / 0.5″ Division value: 0.001 mm / 0.00005″ Sample diameter: 5~120 mm (other sizes can be customized) Sample height: 5~330 mm (other sizes can be customized) Power Supply: AC 220 V 50 Hz Dimensions: 460 mm (L) × 365mm (W) × 740mm (H) Net weight: 24 kg
Introduction: The CHY-G electronic wall thickness gauge is suitable for measuring the thickness of the bottom and wall of glass and plastic bottles in industries such as food, medicine, and cosmetics. It can meet the measurement of wall thickness and bottom thickness of products such as infusion bottles, beer bottles, oral liquid bottles, ampoules, penicillin bottles, PET plastic bottles, etc.
