Model NumberWZZ-2B

Brand NameYIMA

Payment TermsT/T, paypal

Applications
Photoelectric detection and automatic servo control , backlit LCD display , clear and intuitive test data , save three retest results, and calculate the average , with a RS232 interface , can transfer data to a PC.

Technical parameters
Measurement mode : Optical Rotation
Source: Carolina luminosity + filter,
Wavelength 589.44nm
Measuring range : ± 45 ° ( optical rotation )
Minimum reading : 0.001 ° ( Rotation )
Indication error : ± 0.02 ° (-15 ° ≤ ≤ + 15 ° Rotation time )
               ± 0.05 ° ( rotation <-15 ° or rotation > + 15 ° time )
 Repeatability ( standard deviation s): ≤0.01 °
Display: 5 LCD
Tube : 200mm, 100mm
Samples can be measured lowest transmittance : 10%
Output Communication interface : RS232
Power : 220V ± 22V, 50Hz ± 1Hz
Instrument Size 600mm × 320mm × 220mm
Instrument Weight : 28kg
