Introduction: Real-time instrument status diagnosis: Real-time monitoring of the working status, performance indicators and communication status of the instrument to ensure that the instrument is always in a stable working state. Temperature-stable high-sensitivity DLATGS detector module: stabilizes the relative responsivity of the detector, ensuring high sensitivity and good repeatability and stability of infrared spectrum analysis. "Internet + detection" instrument design with optional multi-communication methods: Ethernet interface is used for data transmission, and WIFI wireless communication mode can also be selected to adapt to the development trend of "Internet + detection" instruments for users to carry out interconnection testing, remote operation and Build a basic platform for maintenance, data cloud computing, etc. Features: 1. High-sensitivity optical system design: Corner-type Michelson interferometer combined with fixed mirror adjustment technology (utility model ZL 2013 20099730.2: fixed mirror adjustment mechanism), which can ensure the long-term stability of the optical system without additional complex circuits. The mirror gold-plated treatment ensures the detection sensitivity of the instrument with a large luminous flux. 2. High-stability modular partition design: The instrument adopts a modular design, which is arranged on a cast aluminum base, with a compact structure. It comprehensively balances the mechanical firmness and partition heat dissipation design, which improves the anti-deformation, anti-vibration and anti-temperature drift of the instrument. It greatly improves the mechanical stability and long-term working stability of the instrument. 3. Intelligent multi-sealed moisture-proof design: The interferometer has multiple-sealed moisture-proof structure design, large-capacity visual and easy-to-replace desiccant structure design, real-time monitoring of the internal temperature and humidity of the interferometer, and avoids the optical path system from being interfered by high temperature, high humidity and chemical corrosion. . 4. Integrated innovative electrical system: integrated high-sensitivity DLATGS detector pre-amplification technology, dynamic gain amplification technology, high-precision 24-bit A/D conversion technology, real-time control and data processing technology, digital filtering and network port communication technology to ensure Real-time acquisition and high-speed transmission of high-quality data. 5. Good anti-electromagnetic interference ability: The electrical system meets the requirements of CE certification and electromagnetic compatibility design specifications, reduces external electromagnetic radiation from the design and process, improves the anti-electromagnetic interference ability of the system and the reliability of the whole machine, and meets the requirements of green instruments design concept. 6. High-intensity light source component design: The high-intensity and long-life infrared light source module with high energy distribution in the fingerprint area adopts a spherical reflection cavity design to obtain uniform and stable infrared radiation. The external isolation light source module and the large space heat dissipation cavity design make the instrument have high thermal stability and stable optical interference. 7. High-flexibility design with rich accessories: large sample room design is adopted, and the fixed holes for the installation of accessories are reserved. 8.The commercially available conventional accessories and special accessories can be flexibly configured according to the user's specific test and use requirements, and can be selected for the user. With new accessories reserved space.
Introduction: Real-time instrument status diagnosis: Real-time monitoring of the working status, performance indicators and communication status of the instrument to ensure that the instrument is always in a stable working state. Temperature-stable high-sensitivity DLATGS detector module: stabilizes the relative responsivity of the detector, ensuring high sensitivity and good repeatability and stability of infrared spectrum analysis. "Internet + detection" instrument design with optional multi-communication methods: Ethernet interface is used for data transmission, and WIFI wireless communication mode can also be selected to adapt to the development trend of "Internet + detection" instruments for users to carry out interconnection testing, remote operation and Build a basic platform for maintenance, data cloud computing, etc.
