Features:
1. The popular micro-water dual-purpose pump finally has a large flow! Break through the small torque limit of brushless motor, pumping flow rate up to 2-3LPM, the highest lift is 7 meters!
2. Imported version free gift: metal quick-change joint (imported SMC brand, integrated in pumping, draining port, rare positive and negative pressure quick-connect fittings, no leakage under negative pressure, domestic quick-connect fittings are often It is a positive pressure quick plug, easy to leak and leak under negative pressure!), the customer self-matching standard SMC tube can quickly and reliably set up the system, avoiding water leakage and air leakage troubles!
3. Very unique pumping and pumping pump, the working medium can be gas and liquid (free of oil and no corrosion, no particles, etc.);
4. It can pump water or pumping gas; it can be idling for a long time without water, dry and not damaged; there is water pumping and gas pumping.
5. High-grade brushless motor technology in the forefront of the industry: It adopts special imported brushless long-life motor, which is very suitable for frequent start-stop or long-term continuous operation conditions. It has strong load capacity; it can run continuously for a long time around the clock, with low energy consumption. Install in any direction;
6. The imported version comes with reverse automatic connection and overload automatic protection. The domestic version has reverse connection protection:
(1) Reverse connection protection: If the positive and negative poles of the pump are not burned, the pump will not work, and after the correct connection, the pump will resume normal operation;
(2) Overload protection: When foreign matter falls into the motor, it may be stuck, and it will automatically protect the machine from stopping and avoid burning the motor;
7. Long life: high-quality brushless motor drive, using better raw materials, equipment, process manufacturing, all moving parts use durable products, improve pump life in all directions.
8. Low interference: does not interfere with surrounding electronic components, does not pollute the power supply, and will not cause the control circuit, LCD screen and other crashes;
9. Really reliable self-priming, self-priming is very fast, high suction stroke (2-3 meters); ultra-small volume (only about 3 hand soaps), low noise, no oil, no pollution, maintenance-free..... .
10. Widely used in medical, scientific research, laboratory, environmental protection and other industries, specific applications include: water sampling analysis, water circulation, water lifting and many other occasions. Technical Parameters:
When doing the pump
Voltage (V DC): 24
Current (A): <0.55
Power (W): <13.2
Opening flow rate (L/min): 2
Suction (M): 2
Maximum lift (M): 7
When doing vacuum pump
Voltage (V DC) : 24
Current (A) <: 0.5
Power (W) <: 12
Average flow rate (L/min): 1.6
Negative pressure (relative pressure) (KPa) : ≈-18
Features:
1. The popular micro-water dual-purpose pump finally has a large flow! Break through the small torque limit of brushless motor, pumping flow rate up to 2-3LPM, the highest lift is 7 meters!
2. Imported version free gift: metal quick-change joint (imported SMC brand, integrated in pumping, draining port, rare positive and negative pressure quick-connect fittings, no leakage under negative pressure, domestic quick-connect fittings are often It is a positive pressure quick plug, easy to leak and leak under negative pressure!), the customer self-matching standard SMC tube can quickly and reliably set up the system, avoiding water leakage and air leakage troubles!
3. Very unique pumping and pumping pump, the working medium can be gas and liquid (free of oil and no corrosion, no particles, etc.);
4. It can pump water or pumping gas; it can be idling for a long time without water, dry and not damaged; there is water pumping and gas pumping.
5. High-grade brushless motor technology in the forefront of the industry: It adopts special imported brushless long-life motor, which is very suitable for frequent start-stop or long-term continuous operation conditions. It has strong load capacity; it can run continuously for a long time around the clock, with low energy consumption. Install in any direction;
6. The imported version comes with reverse automatic connection and overload automatic protection. The domestic version has reverse connection protection:
(1) Reverse connection protection: If the positive and negative poles of the pump are not burned, the pump will not work, and after the correct connection, the pump will resume normal operation;
(2) Overload protection: When foreign matter falls into the motor, it may be stuck, and it will automatically protect the machine from stopping and avoid burning the motor;
7. Long life: high-quality brushless motor drive, using better raw materials, equipment, process manufacturing, all moving parts use durable products, improve pump life in all directions.
8. Low interference: does not interfere with surrounding electronic components, does not pollute the power supply, and will not cause the control circuit, LCD screen and other crashes;
9. Really reliable self-priming, self-priming is very fast, high suction stroke (2-3 meters); ultra-small volume (only about 3 hand soaps), low noise, no oil, no pollution, maintenance-free..... .
10. Widely used in medical, scientific research, laboratory, environmental protection and other industries, specific applications include: water sampling analysis, water circulation, water lifting and many other occasions.
