Aode-310 digital angle of repose tester brief introduction The Aode-310 digital angle of repose tester is a testing instrument developed and produced by our company to measure the angle of repose of powders. The instrument calculates the angle of repose by measuring the height of the cone formed by the powder. The instrument only needs to input the values displayed on the electronic digital measuring ruler into the computer software during measurement, and a test report will be automatically generated. The results of the report will display the measured value of the angle of repose and the evaluation of fluidity. The design of the instrument complies with the national standard GB/T 21060-2007 and the international standard ISO 4324. The instrument mainly consists of a resting angle stainless steel funnel, a measuring platform, a lifting operation platform, a measuring rod, a measuring arm, a 304 stainless steel chassis, a digital display module, etc. characteristic: 1. Testing is convenient, fast, and easy to operate. The electronic digital measuring ruler can directly read the values, and inputting the software can obtain the angle of repose value and fluidity evaluation The main components of the instrument are made of 304 stainless steel, which is easy to clean and does not rust 3. Electronic digital ruler replaces manual reading of values, avoiding errors in manual measurement 4. Equipped with a stirring rod, it can assist in testing powders with poor flowability Technical parameters: Power Supply: 5v Size: 280*280*600 Weight: 8kg Funnel volume: 520ml Funnel outlet: 5, 10, 15, 20, 25
brief introduction The Aode-310 digital angle of repose tester is a testing instrument developed and produced by our company to measure the angle of repose of powders. The instrument calculates the angle of repose by measuring the height of the cone formed by the powder. The instrument only needs to input the values displayed on the electronic digital measuring ruler into the computer software during measurement, and a test report will be automatically generated. The results of the report will display the measured value of the angle of repose and the evaluation of fluidity. The design of the instrument complies with the national standard GB/T 21060-2007 and the international standard ISO 4324. The instrument mainly consists of a resting angle stainless steel funnel, a measuring platform, a lifting operation platform, a measuring rod, a measuring arm, a 304 stainless steel chassis, a digital display module, etc.
