Main features Single-channel, WinCE operating system, touch screen, small size Continuous real-time hardware AE feature parameters extraction and powerful hardware signal processing capabilities such as digital filters AE Feature parameters: time of hit, counts to peak, amplitude, energy, duration, rise time, counts, RMS, ASL, external parameters, frequency centroid, peak frequency, 5 partial power features Valve leakage detection: frequency filters and AE parameters filters for noise controlling, a lot of AE parameters as criteria and can be correlated to the amounts of leakage, audible alarm Screen displays: AE waveform, FFT spectrum, AE feature parameters line, Parameter correlation diagram of column / linear / point, leakage indication Internal flash memory for storing setups and data files, large-capacity, easy to replace Matching with the standard general AE sensors Same data formats as SAEU2S AE system, also can be converted to txt, excel and other formats Trigger indicator: threshold trigger, external parameters trigger and the software trigger Main specification AE input: single-channel Sampling frequency: 769kHz ~ 10MHz Sampling accuracy: 16bit Signal frequency: 1 KHz ~ 1MHz Sample length: 256kB (maximum) Dynamic range: > 70dB Battery: Lithium battery, 4 hours continuous work Data Interface: USB2.0 full speed interface and Flash memory card socket External parameters: single-channel, 100 KHz sampling frequency, 16bit sampling accuracy, ± 10V input range Host size: ≤ 241mm × 89mm × 36mm, Weight: ≤ 1.13Kg (with battery), operating temperature: -5 °C ~ +45 °C
Main features Single-channel, WinCE operating system, touch screen, small size Continuous real-time hardware AE feature parameters extraction and powerful hardware signal processing capabilities such as digital filters
