Introduction
SP-Max 3500FL main application DNA / RNA / protein quantitation and purity testing Endpoint ELISAs / EIA cell proliferation / cytotoxicity IC50 / LD50 protein quantitative analysis (BARADFORD, BCA, Lowry) immunoassay drug-dissolving enzyme kinetics analysis ADME analysis pharmaceutical analysis LAL endotoxin detection analysis cell (MTT, etc.) identification of bacterial chemotaxis experiment green fluorescent protein nucleic acid detection probe molecule experiments experimental protease assay in herbal penetrate the cell membrane
Calcium Assay membrane potential detection oxidation detect Live / Dead cell viability / Cytotoxicity Assay
NanoOrange protein experiments PicoGreen DNA detection Caspase-3 Apoptosis Detection
CatchPoint cAMP Detection Dual Luciferase Luciferase analysis analysis Tyrosine Kinase Assay
Aequorin Ca2+ analysis dsDNA ELISAs Based chemiluminescence analysis
Features
1, grating monochromator emitting continuous wavelength 190-1000nm, the need for additional filters;
2, with a strong light absorption detection function can be used as ultra trace the use of ultraviolet-visible spectrophotometer;
3, with no fiber optics, optical path variable, small cross-impact, with high sensitivity;
4, can be at the top of fluorescence detection, fluorescence detection can also be carried out at the bottom, with a strong fluorescence analysis;
5, fully enclosed cabinet light, using a photon counting photomultiplier tube for chemiluminescence analysis;
6, with the average multi-point detection technique, may well overcome the problems detected are not allowed to bring a sample of irregularity;
7, the use of advanced virtual thermostat cover technology that can precisely control the temperature of the sample compartment;
8, has a powerful data analysis and instrument control software, highly automated;
9, provides endpoint detection, dynamic, multi-wavelength, full wavelength scans detected in four read modes;
10, can be added with autosampler, accurate reagent is added to meet the rapid chemiluminescent reaction;
Technical Parameters:
1, the excitation wavelength range: 190nm-1000nm;
2, the range of emission wavelength: 220nm-1000nm;
3, the light absorption range: 190nm-1000nm;
4 wavelength selection: grating monochromator, adjustable 1.0nm step
5, the excitation wavelength band: 2-20nm adjustable;
6, wavelength accuracy: <± 0.2nm;
7, measurement range: 0-4.600OD;
8, linear range: (405nm) 0-3.50OD;
9, microplate readings Time: Endpoint: 10 seconds Kinetics: 0.1 seconds Minimum interval
10 for microplates: 6-1536 hole;
11, the vibration plate functions: linear, circular, cross shock;
12, temperature range: room temperature ~ 65 ℃;
13, detector: Photomultiplier tubes (transmission, reflection);
14, means of communication: USB;
15, detection method: light absorption, fluorescence detection at the top, bottom fluorescence detection, chemiluminescence;
SP-Max 3500FL main application DNA / RNA / protein quantitation and purity testing Endpoint ELISAs / EIA cell proliferation / cytotoxicity IC50 / LD50 protein quantitative analysis (BARADFORD, BCA, Lowry) immunoassay drug-dissolving enzyme kinetics analysis ADME analysis pharmaceutical analysis LAL endotoxin detection analysis cell (MTT, etc.) identification of bacterial chemotaxis experiment green fluorescent protein nucleic acid detection probe molecule experiments experimental protease assay in herbal penetrate the cell membrane
