Introduction
The 785nm Raman probe is used in conjunction with the 785nm semiconductor laser and fiber spectrometer to achieve Raman spectrum measurement applications. Equipped with different sampling brackets, it can measure solid, liquid or powder samples. OD8's optical interference filter effectively guarantees the filtering of Rayleigh signals. Features
1.Raman spectrum range: 150cm-1 -4000cm-1;
2.Rayleigh scattered light cut-off depth> OD6;
3.Product assembly process guarantees consistency;
4.The laser start and interrupt can be controlled directly through the probe hardware trigger switch;
5.Start beam consistency: Start @ 150cm-1. Technical parameters
Product Specifications: RPB-785-N-FF
Size: Main body: 102 × 30 × 13 mm / probe: 45 stainless steel
Exit fiber: N.A.
Receive fiber: N.A.
Armor specifications of the combined part: N.A.
Optical fiber (combined section): N.A.
Optical fiber (splitting section): N.A.
Wire harness: N.A.
Trigger device: N.A.
Light path control: N.A.
Connect the laser terminal: FC / PC
Connect spectrometer terminal: SMA905
Applicable laser wavelength: 785nm
8.5mm protective tube can withstand the pulling force: N.A
785 Rayleigh scattering cut-off depth: OD8
Raman spectrum working range: 150cm-1-4000cm-1
Probe working distance: 7.5 mm (standard)
Probe overall exit coupling efficiency: ≥80%
Working temperature: 0 ～ 80 ℃
Working humidity: 5% ～ 80%
Introduction
The 785nm Raman probe is used in conjunction with the 785nm semiconductor laser and fiber spectrometer to achieve Raman spectrum measurement applications. Equipped with different sampling brackets, it can measure solid, liquid or powder samples. OD8's optical interference filter effectively guarantees the filtering of Rayleigh signals.
