Introduction:
PHJ-1 multi-functional constant temperature smooth muscle experiment tank is mainly used in physiological experiments such as smooth muscle intestine and intestines, regulate and maintain the temperature of experimental environment (such as experimental liquid), thus ensuring the physiological activity of isolated smooth muscle, so that the relevant experiments can be carried out smoothly. The device provides a strong guarantee for observing obvious experimental phenomena and obtaining accurate experimental data. Technical Parameters:
1. Temperature adjustment range: room temperature to 100 ° C
2. Maximum heating power: 350W
3. Time required to heat from room temperature to 38 ° C <10 minutes
4. Working voltage AC220V 50Hz temperature adjustment accuracy: 0.1 °C
5. The membrane button adjusts the temperature.
6. Temperature control accuracy: ≤0.2°C
7. Display accuracy: 0.1 °C
8. Display content: actual temperature and set temperature (at the same time)
9. With 2 barrels, the maximum scale is 45ml and 200ml, and the preheating liquid is automatically added through the bottom communication device.
10. With 4 preheated glass tubes, 20ml-3, 60ml-1, can be used as a preliminary liquid storage.
11. The bath tub can be separated from the thermostatic system for easy cleaning and replacement.
12. External separate independent constant temperature circulation and aeration equipment to eliminate the impact of air pump and pump vibration on the barrel.
13. Adjustable gas flow for easy replacement of air or oxygen.
14. Integrated body tissue hook frame and sensor holder, with fine adjustment, when moving up and down the body tissue, the sensor and the isolated tissue move synchronously, without causing tissue damage caused by pulling.
15. Leakage protection device: Yes, operating current 10mA
configuration list:
1. Constant temperature heating base bucket 1
2. Smooth muscle groove and trough base 1 set
3. Constant temperature system external circulation and support device 1
4. Constant temperature liquid circulation silicone tube 3 meters
5. Supply silicone tube 1 meter
6. 20ml quartz glass tube 3
7. 60ml quartz glass tube 1
8. Oxygenation hook 2
9. Linked one-dimensional trimmer 1
10. Stainless steel bracket (40cm) 1
11. Organizational Link 1
12. Supporting power cable 1 set
