Brief introduction: 1. The mq-type semi-automatic three-coordinate measuring instrument adopts the internationally advanced finite element analysis design method, which makes it with strong mechanical structure rigidity, small geometric error, high accuracy, high performance and high stability. 2. The mechanical whole structure adopts the moving bridge structure with fully closed frame with good rigidity and light weight. Its structure is simple, compact, large carrying capacity and good performance. 3. Fix the granite working table with high quality so that it has strong bearing capacity, wide loading and unloading space and is convenient. 4. Three axes adopt high-quality granite with small thermal expansion coefficient, which has the same temperature characteristics, good temperature adaptability, effective deformation resistance, good rigidity and small dynamic geometric error deformation. 5. The three shafts all adopt the static pressure air floating guide rail composed of self-cleaning air bearing with high precision. The bearing has large span, strong anti-angular pendulum ability, small resistance, no wear and more stable movement. 6. The beam adopts the precision beam design technology, with light weight, low center of gravity, strong rigidity and small dynamic error. 7. There are air source brake switch and micro device on all three shafts, which can realize precise positioning of single shaft. 8. The Z axis adopts balance device, which greatly improves the positioning accuracy and stability of the Z axis. 9. The data acquisition system adopts high performance manual three-coordinate special system with good reliability. 10. The software adopts ac-dmis measurement software package with independent intellectual property rights and powerful functions. Its perfect measurement function and online function provide perfect measurement solution for users. Technical parameters: Length measurement system: imported precision grating ruler Resolution: 0.5mm; Measurement range: 500mm x 600mm x 400mm Error of indication: E is no more than 2.2+L/300mm Environmental requirements: 01: the temperature: 20 + 2 ℃ 1 ℃ / h 1 ℃ / m 2 ℃ / 24 h 02: humidity: 40%-70% 03: electrical source: 220V+10%, 50hz-60hz 04: gas source: greater than or equal to 0.55MPa
Brief introduction: 1. The mq-type semi-automatic three-coordinate measuring instrument adopts the internationally advanced finite element analysis design method, which makes it with strong mechanical structure rigidity, small geometric error, high accuracy, high performance and high stability. 2. The mechanical whole structure adopts the moving bridge structure with fully closed frame with good rigidity and light weight. Its structure is simple, compact, large carrying capacity and good performance. 3. Fix the granite working table with high quality so that it has strong bearing capacity, wide loading and unloading space and is convenient. 4. Three axes adopt high-quality granite with small thermal expansion coefficient, which has the same temperature characteristics, good temperature adaptability, effective deformation resistance, good rigidity and small dynamic geometric error deformation. 5. The three shafts all adopt the static pressure air floating guide rail composed of self-cleaning air bearing with high precision. The bearing has large span, strong anti-angular pendulum ability, small resistance, no wear and more stable movement. 6. The beam adopts the precision beam design technology, with light weight, low center of gravity, strong rigidity and small dynamic error. 7. There are air source brake switch and micro device on all three shafts, which can realize precise positioning of single shaft. 8. The Z axis adopts balance device, which greatly improves the positioning accuracy and stability of the Z axis. 9. The data acquisition system adopts high performance manual three-coordinate special system with good reliability. 10. The software adopts ac-dmis measurement software package with independent intellectual property rights and powerful functions. Its perfect measurement function and online function provide perfect measurement solution for users.
