Introduction

 SGH - 500A hydrogen generator is mainly composed of electrolytic system, pressure control system, purification system and display system.Electrolytic hydrogen USES the most advanced membrane separation technology, can make the number of hydrogen gas according to the needs of the output automatically adjust, maintain the stability of the output flow and pressure.
Features:
(1) can replace high pressure hydrogen gas bottle, make laboratory equipment, guarantee the security.
(2) the working process of automatic control, simple operation, maintenance is convenient.
(3) digital display production quantity, facilitate observation instrument working state and fault judgment.
(4) long life, can be continuous or intermittent use, gas is stable, no attenuation.
(5) the over-voltage protection device, safe and reliable.
SGH - 500 hydrogen generator main parameters:
1 output flow: SGH - 300 0-300 ml/min;
   SGH - 500 0-500 ml/min;
2 output pressure: 0 ~ 0.4 Mpa (factory set to 0.4 Mpa) commonly
3: hydrogen purity > 99.999%
Maximum power:

SGH - 300  150w
SGH - 500, 180 w
5 working conditions:
(1), power supply: AC 220 + / - 10%;50 hz
(2), environment temperature:  5 to 40 ℃
6 Relative humidity: < 85%
7 no serious dust pollution environment

Introduction

 SGH - 500A hydrogen generator is mainly composed of electrolytic system, pressure control system, purification system and display system.Electrolytic hydrogen USES the most advanced membrane separation technology, can make the number of hydrogen gas according to the needs of the output automatically adjust, maintain the stability of the output flow and pressure.
