Introduction: The JY series gel imaging analysis system is suitable for observing, photographing and analyzing gel bands after electrophoresis. With the help of high-resolution CCD and zoom lens, the weak electrophoretic band which is difficult to be recognized by naked eye is obtained. The background interference noise is effectively filtered by using special filter group. Meanwhile, the pollution of ethidium bromide (EB) and ultraviolet radiation leakage are controlled to the greatest extent. The electrophoretic results can be easily displayed on the screen, saved, marked or edited, and the experimental report, printed and online can be easily realized Transmission, get rid of laboratorial tedious operation process, achieve the effect that ordinary ultraviolet analyzer or film observation box can't match. Characteristic： 1. Equipped with imported low illumination and high resolution digital CCD, easy to capture weak spectral band, real-time browsing, full screen display and simple operation; 2. equipped with 6 times zoom lens to facilitate scaling observation. 3. the gel is placed in the central indicator light to facilitate the gel to be placed in the center. 4. Intelligent control box: The control functions of zoom, focus, aperture, UV lamp and white light can be realized through the panel; The utility model has the function of opening the door automatically to cut off ultraviolet rays and a UV forced switch for cutting glue; It has the function of UV lamp automatic delay turn off; It has the function of driving and protecting electric zoom lens, RS232 interface or USB interface; Drawer type movable rubber table (equipped with special cutting cover), easy to observe, operate and cut glue; 5. Equipped with ultra-thin (transmission) scale screen conversion board and (reflection) white light source; 6. The multi-layer coating filter group is used to filter the background noise effectively; 7. It can control zoom, focus, aperture, UV lamp and white light through computer; 8. The system is composed of standardized and reliable modular components, which are easy to maintain or replace; 9. Brand computers and printers are optional. Technical parameters: Effective pixel: 1280 × 1024 Pixel density: 10bit Pixel size: 5.4 × 5.4 (μ m) Resolution: 1.4 megapixel SNR: ≥ 56dB; Sensitivity: it can detect dsDNA less than 20pgeb Camera: imported digital CCD with low illumination and high resolution Zoom lens: F = 1:1.2, 2 / 3 inch imported 6x zoom lens Filter: 590 (nm) UV transmission area (w × L): 250 × 200 (mm) Visible light transmission area (w × L): 250 × 210 (mm) Transmission ultraviolet light source wavelength: 302 (nm) Wavelength of reflected ultraviolet light source: 254, 365 (nm) Transmission UV lamp power: 302nm (8W) Reflected UV lamp power: 254nm (11W), 365nm (11W) Overall dimension (L × w × h): 470 × 405 × 820 (mm) Net weight: 29.0 (kg)
Introduction: The JY series gel imaging analysis system is suitable for observing, photographing and analyzing gel bands after electrophoresis. With the help of high-resolution CCD and zoom lens, the weak electrophoretic band which is difficult to be recognized by naked eye is obtained. The background interference noise is effectively filtered by using special filter group. Meanwhile, the pollution of ethidium bromide (EB) and ultraviolet radiation leakage are controlled to the greatest extent. The electrophoretic results can be easily displayed on the screen, saved, marked or edited, and the experimental report, printed and online can be easily realized Transmission, get rid of laboratorial tedious operation process, achieve the effect that ordinary ultraviolet analyzer or film observation box can't match.
