Brief introduction: Used in lithium ion battery during repetitive hit the environment, can complete conventional impact crash test index. Battery collision testing machine according to the standard: in accordance with GB/T 18287-2000 standard requirement. Work: 1. The deceleration lifter driven by dc motor, with the help of scrolling support push impact body, mesa upward movement. 2. When mesa impact body to rise to a certain height, falling into the buffer impact paid when shock pulse generates sinusoid. 3. By adjusting the drop height or change the amount of compression of mesa, can change the impact acceleration value of the pulse. 4. Adjust the cushion thickness and material can change the duration of the pulse 5. Change the rotating speed of dc motor, can change the pulse repetition frequency Technical indicators: 1. The maximum load: 20 kg; 2. The pulse peak acceleration: 30-100 - m/s squared; 3. The pulse duration: 20 to 1 m/s; 4. The crash pulse repetition frequency: 10-80 / min; 5. The biggest drop height: 0-100 - mm; 6. Protection device: door protection, speed protection, zero signal protection; 7. PLC control, man-machine interface operation.
