DECO-PM-4-5L Single Layer Laboratory Ball Mill

Product ID:HZYJywym010

Price: Please inquire PDF Format
Supply Ability:200SETS/MON
Port:SHENZHEN
share:
  • Product Introduction
  • Consulting
  • Model NumberDECO-PM-4-5L
    Brand NameYIMA
    Payment TermsT/T, paypal
    Introduction:
    DECO Deco independent research and development, production and sales of high-speed frequency control tank mill mill is a laboratory sample can also be used as a small batch production of powder grinding equipment, which has a simple structure, the use of fast, safe and energy saving, Continuous working time is long, high efficiency, the material effect is good, is a cost-effective scientific research, teaching, production equipment; configuration of the West Germany brand conversion system, can achieve speed, timing, orientation and other functions , With good controllability, safety and high efficiency;
    Features:
    Simple operation, beautiful appearance;
    Can be a variety of samples at one time;
    Can be intermittent operation, but also for a long time continuous work;
    Can be scheduled according to the requirements;
    Can be a variety of different materials, different specifications of the ball mill can also use;
    Fine grain size, high yield;
    Safe and energy saving, green, durable;
    Easy to maintain;
    Technical indicators:
    Model: DECO-PM-4-5L
    Yield (L): 0.5-20L
    Structure: Horizontal
    Frame size (mm): 700 * 660 * 440 (long * thick * high)
    Control room size (mm): 160 * 660 * 600 (long * thick * high)
    Longitudinal rail length (mm): 424
    Drive shaft length (mm): 610
    Shaft maximum spacing (mm): 258
    Roller maximum spacing (mm): 260
    Work floor: 1
    Number of pots: 4
    Single tank volume (L): 5
    Number of shafts: 3
    Net Weight (kg): 55
    Grinding method: dry / wet / vacuum / inert gas / low temperature
    Loading and unloading method: intermittent
    Transmission: belt drive
    Speed ​​control mode: Promise frequency control
    Main functions: operation, suspension, speed, forward, reverse, alternating operation, intermittent operation, timing, etc.
    Speed ​​range (r / min): 0-300
    Tank speed (r / min): 100
    Rated voltage (v): 220
    Rated power (kw): 0.75
    Frequency (Hz): 50
    Continuous running time (h): 99
    Feed particle size (mm): 15
    Material size (mesh): 1000
    Ball mill Material: stainless steel, manganese steel, nylon, polytetrafluoroethylene, polyurethane, agate, zirconia, alumina, hard alloy, custom
    Ball mill volume (L): 0.5L, 1L, 1.5L, 2L, 2.5L, 3L, 4L, 5L optional
    Porosity: 20-30%
    Use abrasion (g / h): 0.0001

  • Introduction:
    DECO Deco independent research and development, production and sales of high-speed frequency control tank mill mill is a laboratory sample can also be used as a small batch production of powder grinding equipment, which has a simple structure, the use of fast, safe and energy saving, Continuous working time is long, high efficiency, the material effect is good, is a cost-effective scientific research, teaching, production equipment; configuration of the West Germany brand conversion system, can achieve speed, timing, orientation and other functions , With good controllability, safety and high efficiency;
