Features: 1. To form a complete set of probes, including 5 MHZ, 2 MHZ split type twin probes, high temperature probe and various models 2. With functions of automatic correction zero 3. Capture has the smallest readings, the average measurement, limits, difference measurement and other measurement mode 4. The available input the known thickness, dynamic scan read the velocity of workpiece to be measured 5. Switch on idle after a period of time, the instrument will automatically shut down; When the battery voltage is too low, the screen will have corresponding hints 6. It can store 5000 groups of data sets, each set of data set including the measurement and instrument set parameters, such as 7. Can through the USB interface instrument internal archived data sets to the USB drive, to report on the computer editing and data management 8. With small volume, light weight, low power consumption, long continuous working time, and many other advantages Technical parameters: Measuring range: 0.80 ~ 300.0 mm (steel) Material velocity: 1000 ~ 9999 m/s Accuracy: + / - 0.01 mm / + / - 0.1 mm Measurement frequency: 2 times/s Sensitivity: the automatic Zero point correction mode: 4 mm block automatic correction Working frequency range: 0.5 ~ 10 MHz (3 db) Measurement functions: minimum readings capture, average, restrictions on measurement, differential measurement software functions such as optional Measurement mode: R - B1 With the probe: 5 MHZ, 2 MHZ split type twin probes, high temperature probe, etc Data transfer: through USB interface instrument internal archived data sets to the USB drive Storage: 5000 groups of thickness data sets, each set of data sets, including measurement and instrument set parameters, such as Language: Chinese/English optional Unit type: the metric system (mm)/inch (inch) optional Display: monochrome liquid crystal display (with backlight), 128 x 64 pixels Working time: 40 or higher h Alkaline battery power supply mode: two section 7 Working temperature: - 10 ~ 50 ℃ Weight: 120 g (including battery) Size: 65 * 98 * 24 mm (width x height x thick)
Features: 1. To form a complete set of probes, including 5 MHZ, 2 MHZ split type twin probes, high temperature probe and various models 2. With functions of automatic correction zero 3. Capture has the smallest readings, the average measurement, limits, difference measurement and other measurement mode 4. The available input the known thickness, dynamic scan read the velocity of workpiece to be measured 5. Switch on idle after a period of time, the instrument will automatically shut down; When the battery voltage is too low, the screen will have corresponding hints 6. It can store 5000 groups of data sets, each set of data set including the measurement and instrument set parameters, such as 7. Can through the USB interface instrument internal archived data sets to the USB drive, to report on the computer editing and data management 8. With small volume, light weight, low power consumption, long continuous working time, and many other advantages
