Brief introduction: Measurement principle: WBCU DIFF) the principle of laser multi-angle scattering is adopted. The method of impedance method and HGB method are used to measure the RBC PLT and the spectrophotometric method is used. Test items:WBC、NEUT(#,%)，EO(#，%)，BASO（#，%），MONO（#，%），LYMPH（#，%），RBC,HGB,HCT,MCV,MCH,MCHC,RDW-SD,PLT,MPV,PDW,P-LCR,PCT Amount of specimen : Whole blood 200ul ; Peripheral blood 40ul Test speed : 80 samples / hour Analysis mode : CBC + 5DIFF Injection mode : manual open sampling , full automatic sampling Sample type : venous whole blood , peripheral whole blood , pre - dilution Display : 10.4 - inch color LCD touch screen Operation interface : full - Chinese operation interface , custom report form Bar code scanning : built - in bar code scanner Storage : Automatically store at least 35,000 test results ( including scatter plots and histograms ) Printing : Built - in Thermal Printer I / O ports : 4 USB interfaces , 1 parallel print interface , 1 RS232 interface Power supply : 220V , 50HZ ( optional ) Host Size : 520 * 500 * 595mm ( W * D * H ) Autosampler Size : 520 * 260 * 210mm Weight : 60kg Option : handheld bar code reader , external pin printer Performance features: Touch screen design, super color TFT LCD screen. Five classification of two-channel leukocytes and screening function of abnormal cells. Absolute gold ball quantification, using two quantitative techniques, absolute gold ball constant volume and time flow rate monitoring, while ensuring the accuracy of the measurement items. 28 parameters, including a scatter diagram, three histograms. Standard automatic sampler, automatic sample injection, high degree of automation. The sample is automatically mixed and punctured to reduce the risk of infection and to protect the doctor's safety. Built-in bar code scanning, collecting large amount of information, fast input speed. The ceramic rotary blood dividing valve is used to ensure the accuracy of blood division and the accuracy of the test results.
